Button Widget

Definition

The Button Widget allows to display a button on a feature, allowing to redirect the user to another feature.



Configuration

Properties

Properties name

Type

Mandatory

Description

Values

objectTypes

String

NO

This property is mainly used when displaying a button in a search function to limit the display of the button according to the type of object. For example, you could have a dedicated button for each type of object that links to a function dedicated to that type.

An example is available in the Example section.

-

align

String

NO

Used to define the display area of the Widget.

LEFT, RIGHT

authenticationLevelSufficient

Boolean

NO

Used to define if the feature is "sensitive" or not.

If true, to access the Feature, the user will have to upgrade its authentication level (see settings BUM).

true, false

borderless

Boolean

NO

Used to define if the label of the Widget is underlined or not (when the cursor goes over the text).

true, false

circle

Boolean

NO

Used to define if the border of the Widget is circled or not. If false, the border of the Widget is square-shaped.

true, false

color

String

NO

If no color is defined, borderless and circle properties have no effect.

Used to define the color of the label, border and highlight of the Widget.

For available colors, see Metronic Color Library

featureToExecute

String

NO

Used to define the redirection of the user to an immediate execution feature.
This option must be configured in the feature indicated in this tag).

You cannot use both <target> and <featureToExecute> tags in the same Widget configuration.

You need to configure special i18n keys in order to display the pop-up correctly.

id of the feature

icon

String

NO

Used to define if an icon is displayed inside the button.

For available icons, see https://fontawesome.com/v4.7.0/icons/

fa fa-"name of the icon"

label

Boolean

NO

Used to define if the label of the Widget is displayed inside the button or not.

The label will have to be translated by a I18N key: "ui.features."id of the feature".views."id of the view".sections."id of the section".widgets."id of the action".label

true, false

target

ButtonTargetSupport

NO

If no target is defined, the button will have no action.

Used to define the redirection of the user to another feature.

This is a polymorphic property that can be of three different types:

ButtonLinkTarget

Allows to configure a link that will open in the current tab or a new tab.

The “target” property can take two values:

SELF = open link in same tab

NEW_TAB = open link in a new tab

XML
<target xsi:type="ctdbum:LinkTargetType">
   <link>feature://test_user-card-update/{dataKey.id}</link>
   <target>SELF | NEW_TAB</target>
</target>
ModalWidgetTarget

Open a Widget in a modal dialog (for such an action as: reset a password, role dashboard, ...).

The size of the dialog can be controlled by defining a display option on the widget (modalSize : XS ,SM,LG)

XML
<target xsi:type="ctdbum:ModalWidgetTargetType">
   <widgetToOpen id="role-dashboard" xsi:type="ctdbum:RoleDashboardWidgetType">
      ...
   </widgetToOpen>
</target>
ModalTarget

Allows to configure a link that will open in a modal dialog. It is similar to the widgetToOpen case but the modal is fully routable using the (secondary:…) url pattern.

The “onDismiss” property control the behaviour of the primary route (the one behind the modal) after the modal is dismissed.

NONE = Do nothing

REFRESH = Refresh the primary route

XML
<target xsi:type="ctdbum:ModalTargetType">
  <link>feature://test_user-card-read/{dataKey.id}</link>
  <modalSize>LG</modalSize>
  <onDismiss>NONE</onDismiss>
</target>


For a link to a feature:

feature://<featureId>/{dataKey.id}

For a hub Feature: feature://user-hub.user-card-read/{dataKey.id}

For a link to a user task:

task://<action>/<id>

  • task://to-approve/<taskInstanceId>

  • task://about-me/<operationId>

  • task://submitted-by-me/<operationId>

  • task://admin/<operationId>

outline

Boolean

NO

Used to define how to display the configured color.

true (background is white and text is the configured color), false (background is the configured color and text is white)

size

String

NO

Used to define the size of the button.

XS, SM, LG

objectTypes properties

Property name

Type

Mandatory

Description

Values (default value in bold)

objectType

String

NO

The object type for which the button is available

-

Example

Code

Link configuration

XML
<action id="publish-role" xsi:type="ctdbum:ButtonWidgetType">
	<hidden>false</hidden>
    <config>
    	<align>RIGHT</align>
        <authenticationLevelSufficient>false</authenticationLevelSufficient>
        <borderless>false</borderless>
        <circle>true</circle>
        <color>red</color>
        <icon>fa fa-cart-plus</icon>
        <label>true</label>
        <target xsi:type="ctdbum:LinkTargetType">
          <link>feature://role-publication-create/{routeObjectId}</link>
          <target>SELF | NEW_TAB</target>
        </target>
        <outline>false</outline>
        <size>SM</size>
	</config>
</action>

Widget To Open configuration

XML
<action id="role-dashboard" xsi:type="ctdbum:ButtonWidgetType">
	<hidden>false</hidden>
    <config>
    	<align>RIGHT</align>
		<authenticationLevelSufficient>false</authenticationLevelSufficient>
        <borderless>true</borderless>
        <circle>true</circle>
        <color>red</color>
        <icon>fa fa-book</icon>
        <label>true</label>
        <linkTarget>SELF</linkTarget>
        <outline>false</outline>
        <size>XS</size>
        <target xsi:type="ctdbum:ModalWidgetTargetType">
          <widgetToOpen id="role-dashboard" xsi:type="ctdbum:RoleDashboardWidgetType">
        	<hidden>false</hidden>
            <displayOptions>
              <modalSize>LG</modalSize>
            </displayOptions>
            <config>
            	<bordered>false</bordered>
                <title>true</title>
                <search>
                	<actions/>
                    <allowExport>false</allowExport>
                    <columns/>
                    <rowClickActions/>
                    <additionalSearchAttributes/>
                    <displayFrozenOperators>true</displayFrozenOperators>
                    <frozen>NO</frozen>
                    <modes>
                    	<mode>SIMPLE</mode>
                    </modes>
                    <objectReferences/>
				</search>
			</config>
		  </widgetToOpen>
        </target>
	</config>
</action>

Modal Link configuration

XML
<action id="publish-role" xsi:type="ctdbum:ButtonWidgetType">
	<hidden>false</hidden>
    <config>
    	<align>RIGHT</align>
        <authenticationLevelSufficient>false</authenticationLevelSufficient>
        <borderless>false</borderless>
        <circle>true</circle>
        <color>red</color>
        <icon>fa fa-cart-plus</icon>
        <label>true</label>
        <target xsi:type="ctdbum:ModalTargetType">
          <link>feature://role-publication-create/{routeObjectId}</link>
          <modalSize>LG</modalSize>
          <onDismiss>NONE</onDismiss>
        </target>
        <outline>false</outline>
        <size>SM</size>
	</config>
</action>

Restriction depending on objectType (in a Reporting List Widget for example)

XML
<actions>
     <action id="view-entry-internal-btn" xsi:type="ctdbum:ButtonWidgetType">
        <hidden>false</hidden>
        <config>
           <authenticationLevelSufficient>false</authenticationLevelSufficient>
           <borderless>false</borderless>
           <circle>true</circle>
           <color>blue</color>
           <icon>fa fa-eye</icon>
           <label>true</label>
           <linkTarget>SELF</linkTarget>
           <outline>true</outline>
           <size>XS</size>
           <target xsi:type="ctdbum:LinkTargetType">
              <link>features/identity-internal-view/{dataKey.id}/identity-internal-read</link>
              <target>SELF</target>
           </target>
        </config>
     </action>
      <actions>
       <action id="view-entry-external-btn" xsi:type="ctdbum:ButtonWidgetType">
          <hidden>false</hidden>
          <config>
             <authenticationLevelSufficient>false</authenticationLevelSufficient>
             <borderless>false</borderless>
             <circle>true</circle>
             <color>blue</color>
             <icon>fa fa-eye</icon>
             <label>true</label>
             <linkTarget>SELF</linkTarget>
             <outline>true</outline>
             <size>XS</size>
             <target xsi:type="ctdbum:LinkTargetType">
                <link>features/identity-external-view/{dataKey.id}/identity-external-read</link>
                <target>SELF</target>
             </target>
          </config>
       </action>
<actions>
  • Button Dropdown Widget

    Allows to display a button on a feature with a dropdown list which contains several buttons, in order to redirect the user to other features.

  • Button Group Widget

    Allows to display a group of buttons on a feature, in order to redirect the user to other features. This widget cannot be used in the frame actions
